Features
• Wireless calls and music with Stereo Bluetooth®
• Level dependent function (talk through)
• Noise attenuation: SNR 26 dB
• Sound limiter and dosimeter
• Integrated noise cancelling microphone
• Exchangeable Shells
• Foldable
• Stainless steel headband
• Ghost voice guided interface
• Configure menu
Bass Boost
Music Limiter Mode
Surround Balance
Surround Equalizer
External Input
Side tone volume setting
Reset to Factory Default
(A:1). Headband wire (stainless steel)
(A:2) Two-point fastener (headband wire)
(A:3) Ear cushion (PVC foil and Polyester foam)
(A:4) Microphone for surround sound
(A:5) Attenuation cushion (Polyester foam)
(A:6) Inner shell
(A:7) Outer shell
(A:8) Clamp
(A:9) Headband (sheet metal)
A:10). Headband padding (Leather)
(A:11) AUX audio input, 3.5 mm stereo
(A:12) Audio input, J22
(A:13) On/Off/Mode
(A:14) VOL+, VOL –
(A:15) Speech microphone
(A:16) Bluetooth button
(A:17) Charger jack
(A:18) Charger
(A:19) Rechargeable AAA NiMH batteries
(A:20) Stereo cable 3,5mm. FL6CE
(A21) Extra orange shells

Technical Data Specifications
Power: Battery Type: 2 x AAA 1,2-1,5V batteries (Ni-Cd,
Alkaline,
Lithium, Manganese etc), or rechargeable 2 AAA
Ni-Mh batteries (included)
Operating time: Surround + Bluetooth (active) >11h
Surround only + Bluetooth Off >100h
AC power supply: 100-240V. 50-60 Hz
Charging time: 8 hours
Charging Plug: EIAJ Class 2 5V DC
Wireless Connectivity: Bluetooth 2.1
Bluetooth Profiles: Bluetooth headset profile 1.2
Bluetooth hands-free profile 1.5
Bluetooth A2DP profile 1.2
AVRCP 1.0
Bluetooth Range: Up to 10m, class 2
Pairing PIN: 0000
Wired Connectivity: 3,5mm AUX input jack (limited to 82 dB)
Nexus two pin (J22) AUX input jack
Speakers: 27 mm diameter 100 Ohm
Microphone: 6mm Omni directional electret microphone (built in)
Net Weight: 352g (incl. batteries)
Spare Parts and Accessories
Article No Description 3M art no EAN
HY68 SV Hygiene Kit XH001659461 7318640041172
FL6CE 3,5 mm to 3,5 mm cord 11003066724
FL6H J22 to 3,5 mm cord XH001652078 7318640000629
FL6M J22 to 2,5 mm cord XH001652094 7318640010956
TAMT06 J22 to two pin with PTT/mic XH001662747 7318640042612
TAMT06V J22 to two pin with PTT/mic/ang. 11003064257 7318640047501
MT661-D Flexmic/PTT 2,5/3,5mm/angel conn XH001676416
MT661-F Flexmic/PTT 2,5/3,5mm/straight XH001676473
MT53N-11-A44 Boom Microphone
Operating temperature: -20 °C to +55 °C
Storage Temperature: -55 °C to +55 °C
Charging Temperature: +40 °C (Maximum environmental temperature)
Certification: Bluetooth 2.1
PPE 89/686/EEG: CE EN352-1, EN352-4, EN352-6,
EN352-8
EMC 2004/108/EC
R&TTE EN301489-1/-17, EN 300 328
Safety EN 60950
In the box: 1 x Headset (Black)
1 x Charger
2 x Rechargeable batteries
1 x User Instructions
1 x 3,5 mm cable
1 x Quick start guide
2 x Extra orange shells
Inner Packaging: Dimensions (mm): 245x153x113 Weight (g): 1030
Volume (cm3): 4313
Master Packaging: Dimensions (mm): 792x234x260 Weight (g): 10722
Units: 10
The Bluetooth® wordmark and logotype are the property of Bluetooth SIG,
Inc., and all use of them is subject to licensing agreements.
Attenuation
MT16H21FWS5*-*****
NRR=20 SNR=26 db H=29 db M=23 db L=19 db
Frequency (Hz) 63 125 250 500 1000 2000 4000 8000
Mean attenuation (dB) 15.1 11.1 18.2 27.0 23.8 33.4 37.7 38.9
Std deviation (dB) 3.8 2.6 2.3 2.2 2.1 3.6 2.2 3.3
Assumed Protection Value (dB) 11.8 8.5 15.8 24.8 21.7 29.8 35.5 35.5
3M™ Peltor™
WS SportTac™
Warranty:
The warranty does not cover any damage caused by neglected maintenance
or careless handling.
